Dry Powder Mixing Machine For Shampoo Detergent Heating Mixing Tank
Production Discription:
Dispersion mixer can dissolve & mix liquid-liquid, liquid-solid
materials.
With high speed running of blade, the strong shearing, crashing and
friction force is generated.
The dissolving sawtooth blade is made of stainless steel.
The large stress forces break down the agglomerates into small
particle size.
Design Highlights
1. It has clamp device to fix container when under work process.
2. This machine has hydraulic system, stable running, can lift up
and down frequently.
3. Specially made hydraulic cylinder can realize oil-leakage free.
4. This machine is applicable for premixing & mixing materials for
industrial production.
5. Speed control: With frequency inverter to realize various speed
control.
6. The part contacting with materials is: SUS304 or SS316L.
7. Supporting frame: Q235-A.
8. Height adjustment: Hydraulic lifting up or customized.
Specification:
Model | Capacity(L) | Power(kw) | Speed(rpm) | Disc dia(mm) | Stroke(mm) | Hydraulic power (kw) |
WDS-2.2 | 100 | 2.2 | 0-1440 | 150 | 700 | 0.55 |
WDS-4 | 200 | 4 | 0-1440 | 200 | 800 | 0.55 |
WDS-7.5 | 400 | 7.5 | 0-1440 | 230 | 900 | 0.75 |
WDS-11 | 500 | 11 | 0-1440 | 250 | 900 | 0.75 |
WDS-15 | 700 | 15 | 0-1440 | 250 | 900 | 0.75 |
WDS-22 | 1000 | 22 | 0-1440 | 350 | 1100 | 1.1 |
WDS-30 | 1500 | 30 | 0-1440 | 400 | 1100 | 1.1 |
WDS-37 | 1800 | 37 | 0-1440 | 400 | 1600 | 1.1 |
WDS-45 | 2500 | 45 | 0-1440 | 450 | 1600 | 1.1 |
WDS-55 | 3000 | 55 | 0-1440 | 500 | 1600 | 1.1 |
WDS-75 | 4500 | 75 | 0-1200 | 550 | 1800 | 2.2 |
WDS-90 | 6000 | 90 | 0-960 | 600 | 1800 | 2 |
![]() |
